Discovery 4 Seat Heater Control Module 31268907 Land Rover 2009 to 2013

#77

GENUINE LAND ROVER DISCOVERY 4 L319 SEAT HEATER CONTROL MODULE 31268907

Genuine used Land Rover seat heating control module, suitable for applicable Land Rover Discovery 4 L319 models from 2009 to 2013.

This electronic module forms part of the heated front seat system and controls operation of the seat heating elements on appropriately equipped vehicles.

Part Number: 31268907

Cross-Reference Number: 6G9N-14C724-BD

Associated Land Rover OE Number: LR019436

Part Type: Seat Heater Control Module / Heated Seat ECU / Heating Control Unit

System/Application: Front Heated Seat System

Vehicle: Land Rover Discovery 4 L319

Manufacturer: OEM

Condition: Genuine used part

COMPATIBILITY

Confirmed application:

• Land Rover Discovery 4 L319 – 2009-2013

• Discovery 4 2.7 TDV6 – where matching heated-seat system is fitted

• Discovery 4 3.0 TDV6 – where matching module is fitted

• Discovery 4 3.0 SDV6 – where matching module is fitted

• Discovery 4 5.0 V8 – where matching module is fitted

The 31268907 module is also documented on:

• Range Rover Sport L320 – 2009-2013

Compatibility is determined primarily by the seat specification, heating system, electrical connections and module number, rather than engine size.

TECHNICAL INFORMATION

The seat heater control module forms part of the vehicle’s electrically heated seat system.

Its primary function is to regulate operation of the heating elements installed within the seat cushion and backrest.

The module works together with:

• Seat heating elements

• Vehicle climate / heating controls

• Seat wiring harness

• Temperature monitoring components

• Vehicle electrical network

• Relevant control modules

When seat heating is requested, the control system manages electrical power supplied to the heating elements to provide the selected heating level.

HEATED SEAT SYSTEM INFORMATION

Discovery 4 vehicles were available with different seat specifications and equipment levels.

Depending on specification, the vehicle may have:

• Heated front seats

• Different seat upholstery specifications

• Manual or electrically adjustable seats

• Memory seat functions

• Different heating modules and wiring configurations

For this reason, the module number should always be checked against the original component.

COMMON SYMPTOMS / REASONS FOR REPLACEMENT

• Heated seat completely inoperative

• Seat heating works intermittently

• Seat does not reach the selected temperature

• Heating switches on and then stops

• One heated seat works while the other does not

• Diagnostic communication fault relating to seat heating

• Internal control module failure

• Electrical or connector damage

• Replacement required during heated-seat repair

IMPORTANT DIAGNOSTIC INFORMATION

A non-working heated seat does not automatically indicate a failed control module.

Before replacement, check:

• Seat heating element continuity

• Seat wiring harness

• Electrical connectors underneath the seat

• Vehicle fuses

• Power and earth supply

• Heating controls

• Temperature sensor where applicable

• Diagnostic fault codes

Broken heating elements within the seat cushion or backrest can produce symptoms similar to a failed control module.

INSTALLATION

The module is associated with the front seat heating system and may be mounted underneath or within the seat assembly depending on vehicle configuration.

Before working on the front seat electrical system, disconnect the vehicle battery according to the correct Land Rover workshop procedure.

Take particular care around the seat wiring because the front seat assembly also contains SRS / airbag-related components.

Professional installation and diagnostic checking are recommended.

PROGRAMMING / CODING

Depending on the vehicle specification and replacement module, diagnostic configuration may be required after installation.

Where communication or configuration faults remain after replacement, the vehicle should be checked using suitable Land Rover/JLR diagnostic equipment.

IMPORTANT COMPATIBILITY NOTE

Please match the number on your original module before purchasing.

Main number:

31268907

Associated references include:

6G9N-14C724-BD

LR019436

Please also compare:

• Electrical connectors

• Module casing

• Mounting arrangement

• Heated-seat specification

• Original module numbers

A visually similar module is also found under 31268908, so please do not assume that 31268907 and 31268908 are automatically interchangeable.

Do not purchase solely by vehicle model, year or engine size.

CONDITION

Genuine used OEM seat heater control module.

Suitable for applicable 2009-2013 Land Rover Discovery 4 L319 heated-seat applications.

May have normal cosmetic marks from previous use, storage and removal. Please inspect the listing photographs carefully and compare all numbers and electrical connectors with your original module before ordering.

Ideal genuine replacement for a faulty or damaged Land Rover Discovery 4 L319 heated seat control module ECU 31268907.
