Genuine Land Rover Discovery 4 L319 DAB Digital Radio Receiver Module – AH42-19C032-AE / LR019261 – 2010

Genuine Land Rover used DAB digital radio receiver / Digital Audio Broadcasting module, suitable for selected Land Rover Discovery 4 L319 models equipped with the factory DAB audio system.

This electronic module forms part of the vehicle’s factory infotainment and audio system and is responsible for receiving and processing digital DAB radio broadcasts before integrating the audio and station information with the vehicle’s factory entertainment system.

Part Number: AH42-19C032-AE

Land Rover OE Number: LR019261

Alternative Number Format: AH4219C032AE

Part Type: DAB Digital Radio Receiver Module / DAB Tuner

System: Factory Audio / Infotainment System

Application: Digital Audio Broadcasting – DAB

Donor Application: 2010 Land Rover Discovery 4 L319

Manufacturer: Land Rover / JLR

Condition: Used Genuine Land Rover Part

COMPATIBILITY

Land Rover Discovery 4 – L319

Directly confirmed application:

• Discovery 4 L319 – 2010

• Discovery 4 TDV6 HSE application confirmed

• 3.0 TDV6 – 306DT application confirmed

• 5-door SUV

• Automatic transmission application confirmed

• Factory DAB-equipped vehicles

A documented AH42-19C032-AE module was removed from a 2010 Discovery 4 TDV6 HSE with the 306DT engine and ZF 6HP28 automatic gearbox.

The module is also listed specifically for:

Land Rover Discovery 4 L319 – approximately 2009-2014

where the corresponding factory DAB/audio system is installed.

ADDITIONAL LAND ROVER / RANGE ROVER APPLICATIONS

The same AH42-19C032-AE module is also documented on selected:

Range Rover Sport L320

• Approximately 2009-2013

• Factory DAB-equipped vehicles

Range Rover L322

• Approximately 2010-2013

• Factory DAB-equipped vehicles

Therefore, AH42-19C032-AE is not exclusive to the Discovery 4.

However, infotainment-system specification and model year are particularly important, so the existing module number should always be matched before purchase.

TECHNICAL INFORMATION

The AH42-19C032-AE / LR019261 module is a dedicated digital radio receiver used within the JLR factory multimedia system.

Its primary functions include:

• Receiving DAB digital radio broadcasts

• Processing the incoming digital radio signal

• Communicating with the factory infotainment system

• Supplying digital-radio audio to the vehicle’s audio system

• Providing station information to the vehicle display

• Integrating DAB operation with the factory radio controls

• Working with steering-wheel audio controls where fitted

• Communicating with other multimedia modules within the vehicle

The DAB receiver is a separate electronic module and should not be confused with the dashboard radio/head unit, amplifier or navigation module.

DAB DIGITAL RADIO SYSTEM INFORMATION

DAB stands for:

Digital Audio Broadcasting

Unlike traditional analogue FM/AM reception, DAB uses digitally transmitted radio signals.

The factory Land Rover system can involve several separate components, including:

• DAB Receiver Module – AH42-19C032-AE

• DAB aerial / antenna system

• Aerial amplifier components

• Factory audio/head unit

• Central infotainment display

• Audio amplifier depending on specification

• Steering-wheel controls

• Multimedia communication network

• Associated wiring and connectors

A failure elsewhere in the system can therefore cause symptoms that appear similar to a failed DAB module.

VEHICLE NETWORK / MOST INFORMATION

The Discovery 4 infotainment system uses a network of interconnected multimedia modules.

The DAB receiver forms part of this multimedia architecture, and contemporary Discovery/LR4 technical discussions specifically reference the DAB module within the MOST system/module sequence.

This is important when diagnosing a complete infotainment-system failure rather than simply poor DAB reception.

COMMON SYMPTOMS OF A FAULTY DAB MODULE

Replacement may be required due to:

• DAB radio not working

• No digital radio reception

• DAB option unavailable

• DAB stations disappearing

• Radio unable to find digital stations

• Intermittent DAB operation

• No sound when DAB is selected

• Infotainment communication faults

• Module not communicating with the vehicle

• Internal electronic failure

• Water/moisture damage

• Damaged electrical or network connections

A replacement AH42-19C032-AE has been documented by Discovery 4 owners as restoring failed DAB operation.

IMPORTANT DIAGNOSTIC INFORMATION

No DAB reception does not automatically mean the receiver module has failed.

Before replacing the module, also inspect:

• DAB aerial / antenna

• Aerial amplifier

• Antenna connections

• Module electrical connector

• Power and ground supply

• Multimedia/network connections

• Wiring loom

• Relevant fuses

• Infotainment fault codes

• Other modules within the audio system

If the DAB system has poor reception rather than complete failure, the aerial and aerial amplifier system should be checked carefully.

IMPORTANT MODEL-YEAR INFORMATION

JLR changed the infotainment architecture and DAB hardware during Discovery 4 production.

Later vehicles can use different DAB receiver modules, and later-generation modules should not automatically be assumed compatible with an early 2010 vehicle simply because the connectors or casing appear similar.

For a 2010 Discovery 4, matching:

AH42-19C032-AE

and/or:

LR019261

provides the strongest basis for correct replacement.

PART NUMBER INFORMATION

Primary engineering number:

AH42-19C032-AE

Alternative formatting:

AH4219C032AE

Land Rover OE/service reference:

LR019261

These numbers are directly cross-referenced on documented Discovery 4 DAB receiver modules.

INSTALLATION

The replacement module should be installed using the correct Land Rover workshop procedure.

During installation:

• Disconnect the battery where required by JLR procedure

• Inspect all connectors before fitting

• Check wiring for corrosion or damage

• Inspect the aerial connections

• Carefully handle multimedia/network connections

• Install the module securely

• Reconnect the vehicle correctly

• Test DAB station reception

• Check the complete infotainment system for correct operation

• Scan for stored communication faults where necessary

PROGRAMMING / CODING

Because this is an electronic infotainment/network module, do not assume every used replacement will be universally plug-and-play across all Discovery 4 model years and specifications.

A like-for-like AH42-19C032-AE / LR019261 replacement offers the best compatibility.

Depending on vehicle specification and replacement-module configuration, diagnostic configuration may be required.

Programming/Coding: Vehicle/specification dependent

Diagnostic Check Recommended: Yes

Where necessary, suitable JLR-compatible diagnostic equipment should be used to check module communication and vehicle configuration.

IMPORTANT COMPATIBILITY NOTE

Before ordering, please compare:

AH42-19C032-AE

AH4219C032AE

LR019261

Also check:

• Vehicle model and year

• Factory DAB specification

• Existing module engineering number

• Electrical connectors

• Multimedia/network connections

• Aerial connections

• Infotainment system generation

• Module casing and mounting points

• Listing photographs

Do not rely solely on “Discovery 4” when ordering.

Different infotainment and DAB modules were fitted during L319 production, particularly as the multimedia system evolved through later model years.

For a 2010 Discovery 4, matching AH42-19C032-AE / LR019261 directly with the original module is strongly recommended.

CONDITION

Used Genuine Land Rover / JLR Part.

Normal cosmetic marks, scratches and signs of previous installation may be present.

Please inspect all listing photographs carefully for the exact condition, connectors, mounting points, labels and identification numbers.

Ideal genuine Land Rover replacement DAB digital radio receiver / tuner module for a compatible Discovery 4 L319 factory DAB audio system.
