LAND ROVER DISCOVERY 4Front Right Seat Adjustment Motor P0-12006-03-01 2010 RHD

Low stock! Only 1 left
£28.00
£28.00
Tax included.
  • Fully secure checkout
  • Trusted by thousands
  • Rated and reviewed

Want next day delivery? Be quick!

I18n Error: Missing interpolation value "end_date" for "Ends on {{ end_date }}"

Question about this product?

We're happy to help.

#72


GENUINE LAND ROVER DISCOVERY 4 L319 FRONT RIGHT DRIVER SEAT ADJUSTMENT MOTOR P0-12006-03-01


Genuine used Land Rover electric front seat adjustment motor, removed from a 2010 Land Rover Discovery 4 L319 RHD.


This motor forms part of the electrically adjustable front seat mechanism and operates one of the powered seat adjustment functions.


Part Number: P0-12006-03-01

Additional Reference: 0130002617 may appear on related units

Part Type: Electric Seat Adjustment / Control Motor

Position: Front Right Seat

Vehicle Side: O/S – Offside / Driver Side on UK RHD vehicles

System/Application: Electric Front Seat Adjustment System

Manufacturer: OEM Land Rover seat system component

Condition: Genuine used part


DONOR VEHICLE


Land Rover Discovery 4

Chassis: L319

Year: 2010

Steering: RHD – Right-Hand Drive

Position Removed From: Front Right / Driver Seat


COMPATIBILITY


Suitable for applicable vehicles equipped with the corresponding electric seat mechanism, including:


• Land Rover Discovery 4 / LR4 L319

• Confirmed on Discovery 4 L319 front-seat applications using P0-12006-03-01

• Range Rover Sport L320 – additional applications use the same P0-12006-03-01 motor


A 2010 RHD Range Rover Sport L320 3.0 diesel application is specifically documented with P0-12006-03-01, confirming that this motor was used across more than one Land Rover seat application. (eBay UK)


Compatibility depends primarily on the motor number and seat mechanism, rather than engine size.


TECHNICAL INFORMATION


The electric seat contains several individual motors responsible for different adjustment movements.


Depending on its exact mounting position within the seat frame, the motor operates one of the powered seat adjustment mechanisms.


The motor converts electrical power from the seat control system into mechanical movement through the seat’s drive mechanism.


ELECTRIC SEAT SYSTEM


The motor works together with:


• Seat adjustment switches

• Seat wiring harness

• Seat control module where fitted

• Seat drive cables / gearing

• Seat rails and adjustment mechanisms

• Memory-seat system where fitted


Discovery 4 models were available with different seat specifications, so motors should always be matched to the original unit.


COMMON SYMPTOMS / REASONS FOR REPLACEMENT


• One seat adjustment direction no longer works

• Seat moves in some directions but not others

• Motor does not operate when adjustment switch is pressed

• Motor operates intermittently

• Unusual noise from seat adjustment mechanism

• Seat becomes stuck in one position

• Internal motor or gearbox failure

• Replacement required following seat-frame repair


IMPORTANT DIAGNOSTIC INFORMATION


A seat that does not move does not automatically indicate a failed motor.


Before replacement, check:


• Seat fuse and power supply

• Seat adjustment switch

• Wiring and electrical connectors

• Seat control module where fitted

• Motor electrical supply

• Drive cable / gear mechanism

• Seat rails for mechanical obstruction


If the motor can be heard running but the seat does not move, inspect the associated drive mechanism before replacing the motor.


INSTALLATION


Installation normally requires access underneath or inside the front seat assembly.


Depending on motor position, partial removal of the seat or seat mechanism may be required.


Disconnect the battery correctly before disconnecting or removing the front seat because the seat contains SRS / airbag-related electrical components.


Professional installation is recommended.


PROGRAMMING / CODING


The electric adjustment motor itself would normally not require programming or coding.


However, vehicles equipped with memory seats or advanced seat-control systems may require seat-position checks or system initialisation after repair.


IMPORTANT COMPATIBILITY NOTE


Land Rover used several different motors within the same front seat.


Please do not purchase solely because your vehicle is a 2010 Discovery 4.


Match the number:


P0-12006-03-01


Also compare:


• Electrical connector

• Motor casing

• Mounting points

• Drive connection / shaft

• Position within the seat

• Original motor number


This is particularly important because visually similar motors can perform different seat adjustment functions.


CONDITION


Genuine used Land Rover part.


Removed from a 2010 Land Rover Discovery 4 L319 RHD front right / driver’s seat.


May have normal cosmetic marks consistent with previous use and removal. Please inspect listing photographs and compare the motor number, connector and mounting arrangement with your original part before ordering.


Ideal genuine OEM replacement for a faulty or damaged Discovery 4 L319 front right driver’s electric seat adjustment motor.

Type: Seat Motor

Brand: Land Rover

Manufacturer Part Number: P0-12006-03-01
